Introducing our elegant All-Metal Wall Vents in Powder-Coated Matt White. Designed with both aesthetics and functionality in mind, these two-part vents offer a seamless, professional finish to any space.
Key Features:
- Effortless Installation: The drop-in design simplifies the installation process. Simply remove the inner part, secure the outer body to the wall with screws, and then reinstall the inner section. Your installation is complete in just a few easy steps.
- Customizable Finish: These vents can be easily painted to match your walls or other surrounding surfaces, ensuring a cohesive look throughout your space.
Enhance your interiors with these stylish wall vents, perfect for adding a polished touch to any room.
Airflow Performance Data (10 x 37)
Conservative engineering values.
Net free area 67.6 sq in • Area factor Ak 0.469 sq ft • Open area 18% of nominal
| Face Velocity (fpm) | Airflow (CFM) | Static Pressure (in. wg) | Throw 150 / 100 / 50 fpm (ft) |
|---|---|---|---|
| 400 | 188 | 0.01 | 5 / 9 / 18 |
| 600 | 282 | 0.03 | 8 / 14 / 27 |
| 800 | 376 | 0.06 | 10 / 19 / 36 |
| 1000 | 469 | 0.09 | 13 / 23 / 45 |
| 1200 | 563 | 0.13 | 16 / 28 / 54 |
| 1400 | 657 | 0.18 | 18 / 33 / 63 |
| 1600 | 751 | 0.24 | 21 / 37 / 72 |
Notes and Conditions
- Performance values are engineering calculations and estimates and are not yet laboratory certified. Certified ratings tested to ASHRAE 70-2006 and ADC 1062 will supersede this data once testing is complete.
- Airflow (CFM) is derived by continuity from the rated net free area at standard air density of 0.075 lb per cubic foot under isothermal conditions.
- The net free area shown is the conservative perimeter opening. Actual open area is greater, so delivered airflow meets or exceeds the listed values.
- Static pressure is a conservative calculated estimate referenced to the free-area velocity and carries an added margin. Tested values are expected to be lower.
- Throw values are estimates scaled to this product and are pending TRM ASHRAE 70 certification.
- Sound rating data is pending laboratory test.
- Dimensions are nominal and subject to manufacturing tolerance. Consult TRM Metal Products for applications beyond the conditions shown.
Disclaimer
This information is provided for general information only and is subject to change without notice. The values shown are preliminary engineering estimates, are not laboratory certified, and must not be used for code compliance, regulatory submission, or life safety system design until certified ratings are issued. Selection of the product and verification of its suitability for a given application are the responsibility of the system designer and purchaser. Installed performance varies with duct design, system static pressure, installation quality, and field conditions, all of which are outside the control of TRM Metal Products. To the fullest extent permitted by law, this data is provided as is, without warranty of any kind, express or implied, including any implied warranty of merchantability or fitness for a particular purpose, and TRM Metal Products assumes no liability for any loss, cost, or damage arising from its use or from reliance on it. All product names and trademarks are the property of their respective owners. TRM Metal Products is not responsible for typographical errors.
